Homelable is a self-hosted network and infrastructure visualizer—think “interactive whiteboard of your whole lab with live status and device discovery baked in”—and it’s trending because Little Mister and everyone else running more than three Raspberry Pis realized Home Assistant’s built-in network topology view is basically a crayon drawing by a toddler. Three thousand GitHub stars in six months says people are hungry for something that actually maps who’s talking to whom without requiring a subscription, a cloud relay, or a login to a vendor’s “unified dashboard” that’s really just a data harvester. The momentum matters because it signals that this gap was real—not a hypothetical “nice to have,” but a thing people actively notice and complain about once they reach a certain scale.

Let me cut to it: this belongs in my house. Specifically, it fills a gap I’ve been meaning to address—network/infrastructure visualization that isn’t a half-baked dashboard in HA or a stray Grafana dashboard I keep forgetting to update. Here’s what it would touch.

What it replaces and augments. Homelable sits alongside Home Assistant, not on top of it—it’s a peer, not a slave. That distinction matters more than it sounds. Home Assistant is a central automation platform; it owns the flow of logic and events. Homelable is a witness to your infrastructure; it collects state without moving the decision tree. It pulls from the systems I already run: Zigbee2MQTT (mesh topology, LQI, routing), Z-Wave JS UI (node tree, signal strength), Proxmox (hosts, VMs, LXC guests, resource stats), and optionally the network scanner it ships with (nmap-based discovery across your CIDR ranges). It doesn’t control anything; it watches, visualizes, and tells me what’s online or dead. That’s exactly what I need without another control plane poking at my automations.

The topology pull from Zigbee2MQTT is where this gets real. Zigbee meshes are invisible to most HA users—you know “bulb is on” or “bulb is off,” but you don’t see the routing tree, the hop counts, or the LQI (link quality indicator) that tells you why a message went through a repeater on the far side of the house instead of the closest one. Homelable pulls that full mesh picture—which device talks to which, with what signal strength—and lets you eyeball why your bedroom sensor is sluggish (probably routing through your kitchen repeater instead of the hub, which means weak signal and longer hops). Z-Wave is similar; Z-Wave JS UI keeps node information in its own database, but it’s scattered across multiple screens and status indicators. Homelable consolidates it into one canvas where you see every Z-Wave node, its routing neighbors, and its signal path. Proxmox integration is the other big win: instead of logging into the Proxmox UI to see which VMs are running or manually tracking which guest is consuming how much memory, Homelable pulls your entire infrastructure tree—physical hosts, VMs, LXC containers, their resource allocations and current usage—and merges it with the network picture. If you have a Proxmox host running three VMs and each VM has IoT devices, you suddenly see the full stack: physical hardware → virtual guests → network services → smart devices. That’s visibility you don’t get from HA or Proxmox alone.

It also handles what HA deliberately ignores: floor plans (position devices on a room photo), rack diagrams (physical patch cables, U-height gear placement), multi-canvas layouts (separate “Core Infrastructure,” “IoT Mesh,” “Lab Gear” views), and status checks via ping/HTTP/TCP/SSH. If something’s online, the canvas lights up green. If it’s dead, red. Clean. The floor plan feature is particularly useful if you’re troubleshooting coverage—you upload a photo of your house, mark where your Zigbee repeaters are, and then see which devices are far from the nearest repeater on the same diagram. You can visually correlate “this device is sluggish” with “it’s physically located in the corner farthest from any repeater,” which is obvious in retrospect but easy to miss when you’re managing devices from scattered across a web interface. Rack diagrams serve the same function for your server closet: you position your patch panels, switches, and equipment on a diagram, label the ports, and then mark which devices are physically connected where. If a port goes offline, you don’t have to hunt through cables to figure out which equipment is affected; it’s right there on the diagram.

The deployment story. Docker container (backend, frontend, optional MCP server), SQLite for state (no Postgres required—it’s a few MB even at 100+ devices), tiny footprint (~300–400MB RAM total, negligible CPU except during scans). Proxmox LXC is supported. Build-from-source path exists if you need to patch something. The whole rig comes up in fifteen minutes, and you point it at your MQTT broker, your Proxmox API token (read-only, optional), and your network CIDR ranges. That’s it. No cloud accounts, no phone-home telemetry, no “unified billing portal”—just a local web app that understands your gear.

The Docker deployment is the default path, and it’s genuinely frictionless. The image includes both the backend API and the frontend web app, so you’re not juggling two containers or wiring up networking between them. SQLite as the state store is a deliberate choice—it avoids the operational overhead of running a Postgres database just to hold a few MB of device records and scan history. Most homelab users don’t need distributed writes or horizontal scaling of a topology database; you’re running this on one machine, querying it from a web browser, occasionally triggering a scan or approval action. SQLite is faster and simpler than any networked database. The fact that it stays at a few MB even with 100+ devices shows the schema is lean—you’re not storing redundant data or bloat. The RAM footprint is also honest: 300–400MB is what Homelable actually uses in steady state, not marketing fluff like “as low as 50MB” when the real number is 250MB on startup. CPU is negligible outside of active scans because the main loop is just polling via MQTT or HTTP on a schedule; the expensive work (network scanning, OS fingerprinting) only happens when you trigger a scan.

The Proxmox LXC support is worth noting because it shows the author thought about homelab deployment patterns. A lot of us run all our services in LXC containers instead of Docker on a host or separate VMs—it’s lighter weight than VMs, you get isolation, and you can manage the whole ecosystem from one Proxmox UI. If Homelable only supported Docker-on-a-host, you’d have to either dedicate a VM to it or run it on your bare metal. LXC support means you spin up a lightweight container, plop Homelable in it, and it runs alongside your other services with minimal overhead. Build-from-source is there if you need to patch something or customize the image, but 99% of users won’t need it. The fifteen-minute setup time is real—it’s not “fifteen minutes after you’ve read the docs three times”; it’s literally docker run or lxc launch, point it at your broker and API token, and you’re seeing your topology.

The integration surface. Zigbee2MQTT? Pull full mesh topology with LQI in one click, then keep it in sync on a schedule if you want. That one-click is important: Homelable understands the MQTT schema that Zigbee2MQTT uses, so you don’t have to export, transform, or manually map topics. You give it your MQTT broker address (probably mqtt://homeassistant.local or whatever your HA instance is), and it reads the entire mesh state from the published topics. LQI is the link quality indicator—it tells you signal strength between hops, from 0 (basically no signal) to 255 (perfect). Homelable pulls those values and can color-code the links or flag nodes that are only reachable through weak links. If you keep auto-sync enabled, Homelable polls your MQTT broker on a schedule (configurable, defaults to something reasonable like every five minutes) and updates the mesh topology. If new devices join or a node drops off the mesh, you’ll see it reflected in the canvas without manual intervention. That’s real-time(ish) visibility without hacking Home Assistant or running another tool.

Z-Wave JS? Same deal—MQTT-based, no special sauce needed. Z-Wave JS UI publishes its state to MQTT under a known topic structure, and Homelable subscribes to it. You get the node tree (which device is which), signal strength, and node status. MQTT-based is the key pattern here—most modern automation tools publish their state to MQTT, and Homelable uses that as a common language instead of requiring separate plugins for each platform.

Proxmox integration is where Homelable shows its teeth. Feed it a read-only API token (which you create in the Proxmox UI and never needs to touch your actual infrastructure), and it imports your entire guest tree—hosts, VMs, LXC, resource specs, current usage. It then merges duplicates against devices the scanner already found, so if your scanner discovered 192.168.1.50 and Proxmox says “that’s the Ubuntu LXC container named ‘docker-host’,” Homelable stitches them together into one node labeled correctly. That means your diagram shows both the network-visible device and its logical identity in your virtualization layer. The resource stats (CPU, memory, disk usage) get pulled too, so you can see at a glance if a VM is over-committed or running hot.

Network scanner is nmap-based discovery across configurable CIDR ranges. You tell it which subnets to scan (e.g., 192.168.1.0/24 and 192.168.2.0/24 if you have two subnets), and it runs nmap to find live hosts, fingerprint their OS, and probe common services. Optional deep scans on custom ports let you find services you’ve deliberately hidden behind non-standard ports—if you’re running SSH on port 2222 or HTTP on a weird port number, a default scan might miss it, but a targeted deep scan on those ports will find it. The fingerprinting is decent; it’s not going to distinguish a five-year-old Debian from last week’s, but it’ll catch “this is definitely Windows,” “this looks like a Raspberry Pi,” etc. The results get added to your canvas automatically.

Status checks are the monitoring layer: Ping, HTTP GET (is the /health endpoint 200?), TCP connect, SSH probe, Prometheus scrape, or raw health endpoint poll. You assign methods per node type—“all my Proxmox hosts, check them via TCP on port 8006”; “all my web services, check via HTTP /health”; “everything else, try ping”—and Homelable cycles through them on a schedule. If a check fails, the node turns red. If it recovers, it turns green. None of this calls out to the internet; it’s all local probing. That’s a huge difference from cloud-based monitoring tools, which phone home and depend on external infrastructure to tell you if your local device is online. Here, Homelable is sitting on your network, checking your devices directly.

Here’s where it gets interesting for me. The MCP server. Homelable ships with an AI-assistant integration point that lets me—or any MCP-aware client—query the topology, approve discovered devices, trigger scans, or even create/update canvas nodes programmatically. That MCP interface is small but powerful: you can ask for the full topology (all nodes, edges, metadata), filter by device type or status, or get a report of recent changes. “Create a node” or “update node properties” means you can wire this into automation—imagine a script that discovers a new device, asks an AI to classify it based on its fingerprint and service list, and automatically adds it to the right canvas with the right icon and labels. Approval workflows are another angle: unapproved devices can exist in the “pending” state, and you or an automation can review them and approve them into the main topology.

That means you could theoretically ask “what new devices joined the network in the last hour?” or “show me all Z-Wave nodes with LQI < 100” and an AI client gets structured data back instead of your having to manually eyeball the canvas. Claude Code (or Nova, or any MCP-capable client) could run a query, get back JSON describing your topology, and then synthesize a summary: “Your kitchen mesh is healthy, but the bedroom repeater is only reachable through one hop with 60% LQI—consider adding another repeater.” That’s future me either thanking past me or cursing him; we’ll find out. The MCP server also means you could trigger actions from outside—a script in a monitoring tool or automation platform could say “Homelable, run a deep scan of this CIDR range now and tell me what you find.” That’s closer to “infrastructure as a queryable service” than most homelab tools offer.

The catches—and they’re real. SQLite isn’t distributed, so if you want to run Homelable on ten machines simultaneously checking the same canvas, you’ll have contention. Don’t. It’s fine for one active user at a time—exactly my use case. If you’re sharing this with a partner or roommate who might access the web UI at the same time, you’re okay as long as you’re not both triggering scans or adding devices simultaneously. It’s not like Postgres where multiple connections are expected; it’s a single-file store optimized for serial access.

Network scanning runs serially per CIDR range; deep scans (all 65535 ports) are slow as hell, but targeted scans are snappy. If you ask for a deep scan on a /24 (256 addresses), you’re looking at several minutes even with aggressive timeouts. Targeted scans (the default—just check common ports like 22, 80, 443, 8080, 8006) are done in seconds. That’s acceptable; you’re not going to run full deep scans every five minutes anyway. The serial nature is fine for typical homelab scale; even if you have three subnets, running them one after the other means the whole scan takes a few minutes, which is reasonable.

Zigbee/Z-Wave meshes with 200+ devices render fine on modern browsers but lag on older ones. If you’re running Windows Vista or an iPhone 6, you might notice lag when zooming or panning a massive topology. Realistically, you’re probably accessing this on a recent phone, laptop, or tablet, so it won’t be an issue. If you have a truly massive mesh (which is unusual; 200+ distinct Zigbee devices means you have a very dense automation setup), you might benefit from splitting it into multiple canvases.

The tool doesn’t know about UniFi or Grafana natively, so you can’t directly import your UniFi network configuration or Grafana dashboards. But you can add them as nodes and health-check them; the network scanner would find your APs and switches anyway. If you care about UniFi topology (which specific devices are connected to which APs), you’d have to manually add that or bridge it via another tool. For my purposes—“is the network working or dead”—that’s fine.

History (old scans, device logs) doesn’t auto-purge, so if you run weekly scans for a year, you’ll have 52 scan records sitting around. It’s not a space problem (scan history is tiny), but it does mean your database grows by a few kilobytes per scan. Easy to trim by hand or database edit if it bothers you—there’s no automatic cleanup because Homelable respects your data and doesn’t delete things without permission.

Canvas switching is purely visual—each diagram (Core, IoT, Rack, etc.) is independent. You can’t link nodes across canvases (like a device on the “IoT Mesh” canvas linking to its physical host on the “Core Infrastructure” canvas), but you don’t need to. The underlying topology is unified; you’re just viewing it through different diagrams. If a device appears on multiple canvases, it’s the same node logically, just displayed twice for organizational purposes.

Proxmox auto-sync isn’t enabled by default, so it won’t suddenly hammer your Proxmox API; you trigger it manually or set an interval in the config. That’s a thoughtful default—your Proxmox instance is doing real work, and spamming it with API queries every five minutes would be rude. You can sync on-demand or set a long interval (like every hour) if you want automated updates.

Effort: Two to four hours wiring it in end-to-end. Spin up Docker (ten minutes). That’s literally docker run pouzor/homelable or adding it to your docker-compose file and hitting docker-compose up. If you’re running Proxmox LXC, it’s the equivalent—launch an image, give it network access, let it boot. Configure network scanner and run one scan (fifteen minutes). You tell it your local subnets and hit “scan”; it discovers your devices, fingerprints them, and populates the canvas. Point it at your MQTT broker and import Zigbee/Z-Wave (twenty minutes). MQTT connection is one hostname and port; import is one button. Your Zigbee2MQTT and Z-Wave topics get parsed automatically.

Create a Proxmox read-only token and import guests (twenty minutes). In Proxmox, create an API token with read-only permissions on the VM/LXC data, paste it into Homelable, and hit import. It pulls your entire guest tree in one pass. Assign status-check methods to each node type (thirty minutes). This is configuration—you’re saying “check all Proxmox hosts via TCP on port 8006,” “check Zigbee devices via the mesh topology,” etc. Most of it is defaults; you’re just customizing the checks that matter to you. Upload a floor plan image and position your devices on it (twenty to thirty minutes). This is the most manual part—you’re literally clicking and dragging devices to their positions on a room photo—but it’s also the most satisfying because the result is a literal diagram of your house. Optionally wire the MCP server to a Claude client if you’re feeling spicy (twenty minutes). That’s pointing your Claude Code MCP client at the Homelable MCP server endpoint and testing a query. Done. No code changes, no soldering, no firmware flashing. Pure configuration and clicking.

The total time is conservative. If your Zigbee and Z-Wave are already separate from Home Assistant (which is my case), the import is trivial. If they’re built into HA, it’s zero-effort. The Proxmox piece depends on whether you have Proxmox; if you don’t, skip it. The floor plan is the only truly manual part, and you can skip it entirely if you don’t care about physical layout—the topology works fine without visual positioning.

The real win. This is local-first done right. MIT licensed, zero vendor lock-in, no mandatory cloud account or phone-home, no “sync to the cloud for visibility,” no “upgrade to Pro to see more than ten devices.” Just you, your infrastructure, and a diagram that actually shows what’s real. For a homelab running 100+ devices on local hardware (Zigbee, Z-Wave, Proxmox, Grafana, UniFi), this is the missing piece. It doesn’t replace HA or the scanning tools I already have; it ties them all together visually and adds status monitoring on top. And the MCP server means future automation stories—ask an AI to optimize your mesh, suggest redundant links, find dead equipment—are possible without hacking. You’re not limited to what the Homelable UI provides; you can programmatically query and act on topology data.

Compare this to the alternatives. Home Assistant’s built-in topology view is a graph with nodes and edges; it’s clean, but it doesn’t understand mesh quality, physical layout, or virtualization. Proxmox’s UI shows you VMs and containers, but no network topology. UniFi shows you network topology, but only from the UniFi perspective (which APs are which). Grafana dashboards can show status, but they’re not topology-aware. Homelable is the first tool I’ve found that says “I will show you everything, integrated, with status, in a layout that makes sense.” That’s not a feature; that’s a perspective shift.

The local-first angle is the other half of the win. Your topology data never leaves your house. You’re not syncing to a cloud backend, not waiting for API calls to round-trip through vendor servers, not dependent on an external service staying online. Homelable goes down, you restart it; your topology is still there. That’s the right model for infrastructure that’s supposed to be yours.

The only reason not to adopt this is if you’re allergic to running another service, and frankly, if you’re at 100+ devices, that ship sailed three years ago. You’re already running Home Assistant, Proxmox, MQTT, some flavor of monitoring. Adding a fourteen-megabyte Docker image to the fleet is negligible. The value—seeing everything at once, understanding your infrastructure—outweighs the cost of one more service.

Scouted repo: Pouzor/homelable — 3098 stars. Verdict: ADOPT. Desk review, nothing was flashed or installed.
